Air Slider

The air slider chute has no rotating parts when conveying material, easy to maintain, good sealing, no noise, safe and reliable operation, low power consumption, convenient to change the conveying direction, and can achieve multi feeding and unloading.

Breath layer is in the middle of chamber, upper part is the material chamber, lower part is the air chamber. When the gas with a certain pressure is blown into the air chamber, the material is fluidized through the permeable layer, so the material flows inside the chamber like a fluid under the action of gravity. Fan is used as the pressure wind source. The excess air inside the material chamber is drawn away by the dust collector through the exhaust port of the air slider chute.

Technical Parameters Of Steel Wire Belt Bucket Elevator

* Handling material:dry powder material moisture content≤1%,temperature≤150℃.
